ASTM A790/ASME SA790 Pipe,SAF2205/2507 Duplex Steel Pipe
SSDSP37
Price: From $5000-9000USD/TON
Material: S32205, S31803, 1.4462; S32750,1.4410, 2507, F53;
Get QuoteASTM A790/ASME SA790 Pipe,SAF2205/2507 Duplex Steel Pipe,Cold Rolled Pipe
Physical Properties | ||||
Grade | Y.S.MPa min | T.S.Mpa min | Elongation % | Hardness HRC |
UNS S32750 | 550 | 800 | 15 | 20 |
UNS S31803 | 450 | 620 | 25 | 20 |
UNS S31500 | 440 | 630 | 30 | 20 |
UNS Designation | C | Si | Mn | P | S | Cr | Ni | Mo | N | Cu |
max | max | max | max | max | ||||||
S31803 ( F51 ) | 0.03 | 1 | 2 | 0.03 | 0.02 | 21.0 - 23.0 | 4.5 - 6.5 | 2.5 - 3.5 | 0.08 - 0.20 | - |
S32205 ( F60 ) | 0.03 | 1 | 2 | 0.03 | 0.02 | 22.0 - 23.0 | 4.5 - 6.5 | 3.0 - 3.5 | 0.14 - 0.20 | - |
S32750 ( F53 ) | 0.03 | 0.8 | 1.2 | 0.035 | 0.02 | 24.0 - 26.0 | 6.0 - 8.0 | 3.0 - 5.0 | 0.24 - 0.32 | 0.5 max |
S32760 ( F55 ) | 0.05 | 1 | 1 | 0.03 | 0.01 | 24.0 - 26.0 | 6.0 - 8.0 | 3.0 - 4.0 | 0.20 - 0.30 | 0.50 -1.00 |
Duplex stainless steel that was developed to combat common corrosion problems encountered with the 300 series
stainless steels . Duplex describes a family of stainless steels that are neither fully austenitic , like 304 stainless , nor purely ferritic , like 430 stainless . The advantage of a duplex structure is that it combines the favorable qualities of a ferritic alloy ( stress corrosion cracking resistance and high strength ) with those of an austenitic alloy ( ease of fabrication and corrosion resistance ) .
Material Grade | S32205 , S31803 , S32304 , S32750, F51 , F53 , 2205 , 2507 etc |
Outer Diameter | 10.3mm - 1219mm |
Wall Thickness | 1.24mm - 54.59mm |
Length | as per customer's requirement |
Standard | ASTM A789 ; ASTM A790 ; EN 10216-5 etc . |
Application :
1 . Petroleum
2 . Chemical industry
3 . Instrument
4 . Industrial transportation
5 . Mechanical structure industry
6 . Need high corrision ability pipe's industry , such as offshore industry etc
20ft GP : 5898mm ( Length ) x 2352mm ( Width ) x 2393mm ( High )
40ft GP : 12032mm ( Length ) x 2352mm ( Width ) x 2393mm ( High )
40ft HC : 12032mm ( Lengh ) x 2352mm ( Width ) x 2698mm ( High )
20 feet container load 25tons coils whose length is under 5.8m
40 feet container load 25tons coils whose length is under 11.8m
